Brief Introduction of Several Kinds of Jacketed Kettle

✿ Tilt-type agitating jacketed kettle uses steam as a heating source. Material mixing is made of stainless steel, has features of scraping bottom and edge, nonstick skillet, without stirring dead.
✿ Electric heating jacketed kettle uses electric as the heat source, an interlayer is equipped with heating rods, thermocouple and heat conduction oil (self-made), can reach 320 degrees. It is controlled by an electronic control box, equipped with an automatic temperature control system.
✿ Vertical agitating jacketed kettle uses steam as heating mode, which is also named vertical steam heating double-layer cauldron. usually composed of pot and hold feet, and the pot is the double layer structure formed by inside and outside spherical pot, the middle layer can add steam to steam heating.
✿ Tilting jacketed kettle is consisting of pan, plank, worm wheel, and worm. The pan can turn within 180°, so it is easy for taking out the material. The equipment can configure the mixing system according to different craft demand.

_jacketed cooking kettle

Jacketed Kettle Classifications

According to the different structure, heating mode and demand, the jacketed kettle can be divided into the following several types.
☞ Structure: tilting jacketed kettle and vertical jacketed kettle.
☞ Heating mode: electric heating jacketed kettle, steam heating jacketed kettle and gas heating jacketed kettle.
☞ Process need: jacketed kettle with agitating and jacketed kettle without agitating.

Jacketed Kettle Features

♣ Efficient heating

The jacketed kettle often uses certain pressure steam or electric heating as a heat source. It has many good features such as large heating area, high thermal efficiency, uniform heating, short liquid boiling time, easy to control the heating temperature and other characteristics.

♣ Safe and convenient.

The inner layer of this kettle is made of austenitic stainless steel, equipped with pressure gauge, safety valve, and electric cabinet, featured by good appearance, easy operation, and reliable insulating property.

The Wide Application of Jacketed Kettle

wide application of jacketed kettle

☂ Widely applied in food processing such as candy, medicine, dairy, alcohol, cake, sweetmeat, beverage, can, etc. It can be used to boil soup, cook, stew, and porridge in some large restaurants and canteens.
☂ It is considered to be the ideal equipment in the food processing area to improve cooking quality, shorten cooking time and improve cooking conditions.

Jacketed Kettle Technical Data

Model  50L  100L 200L 300L 400L 500L 600L
Volume(L) 50 100 200 300 400 500 600
Heat transfer area(m2) 0.39 0.77 1.29 1.34 1.98 2.30 2.70
ID(mm) 550 700 800 900 1000 1100 1200
Depth(mm) 400 450 530 620 670 710 730
The height of the stand side(mm) 100 100 130 170 175 160 130
Power of electric heating pipe(KW) 12 18 24 36 42 48 48
Heating up time(min) 25 25 42 48 55 60 65
Mixing power(KW) 0.55 0.75 0.75 0.75 1.1 1.5 1.5
Speed of the mixer(R/min) 21-72optional 21-72optional 21-72optional 21-72optional 21-72optional 21-72optional 21-72optional
