Rotary Nut Roaster Machine

//Rotary Nut Roaster Machine

Rotary Nut Roaster Machine Introduction

Nut roaster machines is an ideal roasting device and can roast a wide range of nuts like peanut, chestnut, walnut, almond nut, broad bean, coffee bean, sunflower seed, and other granulated nuts. It is popular among supermarkets, bazaar, station and many other sites where people gather around.

Rotary Nut Roaster Machine Introduction

Rotary Nut Roasting Machine Structure

It is composed of upper feeder, discharging hole, machine rack, warming cotton, an inner cylinder body, speed reducer, electricity controlling box, and driving equipment. Clockwise moving is roasting evenly and the opposite direction is discharging.

Rotary Nut Roasting Machine Structure

Peanut Roaster Features

▷Average heating and can keep food warm, no operator to turn.
▷High roasting efficiency, various output choices from 80-650kg.
▷Convenient operation, just press the switch on the electricity box.
▷Labor and energy saving, sanitary and hygiene.

Peanut Roaster Features

Nut Roaster Working Principle

roasted nutsNut roaster is powered by coal ( electricity, oil, gas or infrared ray) and works in the principle of heat radiation conduction. During roasting, the food has no contact with smoke or fire and is driven by spiral flights to roll continuously. The heating is distributed averagely which ensures good roasting quality and color.

How to Maintain Nut Roasting Machine

☞Periodically oil the motor and bearings.
☞Check the electrical circuit and line to avoid a sudden break.
☞Adjust the space room between rotating drum and plate to the exact 2mm for normal use.

Rotary Nut Roaster Technical Data

Model MHK-1 MHK-2 MHK-3 MHK-4 MHK-5
Dimension(mm) 3000*1200*1700 3000*2200*1700 3000*3300*1700 3000*4400*1700 3000*5500*1700
Output (kg/h) 80—120 180—250 280—350 380—450 500-650
Power 1.1kw 2.2kw 3.3kw 4.4kw 5.5kw
Electricity 18kw 35kw 45kw 60kw 75kw
Gas 0.9-2kg 1.8-3kg 2.6-4kg 4-6kg 6-8kg

Working Video of Rotary Nut Roasting Machine
